brainfxxck

Modern C++ brainfuck interpreter/compiler with LLVM 18

brainfxxck is a high-performance brainfuck interpreter and compiler that leverages LLVM 18's JIT compilation capabilities to achieve significantly faster execution speeds compared to traditional interpreters.

Features

• JIT Compilation: Default execution mode using LLVM's ORC JIT engine for fast runtime performance
• Static Compilation: Compile brainfuck programs to native executables
• AST Optimizations: Automatic optimization of brainfuck code at the Abstract Syntax Tree level:
  • Combines consecutive +/- operations into single instructions
  • Combines consecutive >/< operations into single instructions
  • Optimizes simple clear loops ([-] or [+]) into direct cell assignments
• Multiple Output Formats: Generate LLVM IR, assembly, bitcode, or object files
• Configurable Optimization: Choose optimization levels from 0-3 (default: 2)
• Standard Brainfuck: Full support for the standard brainfuck language (8 instructions)

Performance

brainfxxck achieves significant performance improvements over traditional interpreters through LLVM JIT compilation and optimizations.

Benchmark Results

Performance comparison on mandelbrot-huge.bf:

Implementation	Real Time
brainfxxck	0m28.230s
brainfuck	1m24.638s

Result: brainfxxck is approximately 3x faster than the traditional brainfuck interpreter.

Requirements

• LLVM 18 or later (required)
• CMake 3.20 or later
• C++17 compatible compiler (GCC 7+, Clang 5+)
• Build tools (make, ninja, etc.)

Building

Step 1: Clone and Navigate

cd brainfxxck
mkdir build
cd build

Step 2: Configure with CMake

cmake ..

CMake will automatically:

• Detect LLVM 18 installation
• Fetch PEGTL (Parsing Expression Grammar Template Library) if not found
• Configure the build system

Step 3: Build

make

Or with ninja (faster):

cmake -GNinja ..
ninja

Step 4: Install (Optional)

make install

This installs:

• brainfxxck executable to bin/
• brainfxxck_lib library to lib/
• Header files to include/

Usage

Basic JIT Execution (Default)

Run a brainfuck program with JIT compilation:

./brainfxxck program.bf

Compile to Native Binary

Compile a brainfuck program to a standalone executable:

./brainfxxck --compile -o program program.bf
./program

Optimization Levels

Control optimization level (0-3):

# No optimization
./brainfxxck -O0 program.bf

# Default optimization (O2)
./brainfxxck -O2 program.bf

# Maximum optimization
./brainfxxck -O3 program.bf

Output Formats

Generate different intermediate representations:

# LLVM IR
./brainfxxck --emit-llvm -o program.ll program.bf

# Assembly
./brainfxxck --emit-asm -o program.s program.bf

# LLVM Bitcode
./brainfxxck --emit-bc -o program.bc program.bf

# Object file
./brainfxxck --compile -o program.o program.bf

Disable AST Optimizations

Run without AST-level optimizations:

./brainfxxck --no-optimize program.bf

Command-Line Options

Usage: brainfxxck [OPTIONS] <file>

Options:
  --jit              Run using JIT compilation (default)
  --compile          Compile to native binary
  -o <output>        Output file for compilation
  -O<level>          Optimization level (0-3, default: 2)
  --emit-llvm        Emit LLVM IR instead of binary
  --emit-asm         Emit assembly instead of binary
  --emit-bc          Emit LLVM bitcode instead of binary
  --no-optimize      Disable AST optimizations
  --help             Show this help message

Architecture

brainfxxck consists of several key components:

Parser (src/parser.cpp)

Uses PEGTL (Parsing Expression Grammar Template Library) to parse brainfuck source code into an Abstract Syntax Tree. The parser:

• Handles all 8 brainfuck instructions (+, -, >, <, ., ,, [, ])
• Validates bracket matching
• Ignores non-brainfuck characters

AST (src/ast.cpp)

The Abstract Syntax Tree representation includes:

• Add: Increment/decrement operations
• Move: Pointer movement operations
• Input/Output: I/O operations
• Loop: Loop constructs with nested instructions
• Set: Direct cell assignment (from optimizations)

The AST optimizer performs:

• Combining consecutive Add operations
• Combining consecutive Move operations
• Converting simple clear loops to Set instructions

Code Generator (src/codegen.cpp)

Generates LLVM IR from the optimized AST:

• Creates a main function that allocates and initializes the tape
• Generates optimized LLVM IR for each instruction type
• Handles tape wrapping for pointer operations
• Links with standard C library functions (putchar, getchar, malloc, free)

JIT Engine (src/jit.cpp)

Uses LLVM's ORC JIT framework to:

• Compile LLVM IR to machine code at runtime
• Apply LLVM optimization passes
• Execute the compiled code directly
• Manage memory and symbol resolution

Compiler (src/compiler.cpp)

For static compilation:

• Generates object files, assembly, or LLVM IR
• Applies target-specific optimizations
• Links with system linker to create executables

Examples

The examples/ directory contains a comprehensive collection of brainfuck programs:

• Hello World: examples/hello.bf
• Mathematical Programs: examples/math/ (Fibonacci, prime numbers, π calculation, etc.)
• Mandelbrot Set: examples/mandelbrot/ (including mandelbrot-huge.bf used in benchmarks)
• Sorting Algorithms: examples/sort/
• Games: examples/gameoflife.bf, examples/lost-kingdom.bf
• Quines: examples/quine/ (self-replicating programs)
• Compilers/Interpreters: examples/compiler/, examples/interpreter/

Running Examples

# Hello World
./brainfxxck examples/hello.bf

# Mandelbrot set (benchmark program)
./brainfxxck examples/mandelbrot/mandelbrot-huge.bf

# Compile and run
./brainfxxck --compile -o hello examples/hello.bf
./hello

Project Structure

brainfxxck/
├── CMakeLists.txt          # Build configuration
├── LICENSE                  # MIT License
├── README.md               # This file
├── include/
│   └── brainfxxck/
│       ├── ast.hpp         # AST node definitions
│       ├── codegen.hpp     # LLVM IR code generator
│       ├── compiler.hpp    # Static compiler interface
│       ├── jit.hpp         # JIT engine interface
│       └── parser.hpp      # Parser interface
├── src/
│   ├── main.cpp            # Command-line interface
│   ├── parser.cpp          # PEGTL-based parser
│   ├── ast.cpp             # AST implementation and optimizer
│   ├── codegen.cpp         # LLVM IR generation
│   ├── jit.cpp             # JIT execution engine
│   └── compiler.cpp        # Static compilation
└── examples/               # Brainfuck example programs
    ├── hello.bf
    ├── mandelbrot/
    ├── math/
    └── ...

License

See LICENSE for the full license text.
