Semantic Ethical Glass Box (SEGB)

SEGB is a semantic logging stack for human-robot interaction. It captures interaction evidence as connected RDF knowledge so you can inspect not only what happened, but also who was involved, which component or model acted, and how the full trace fits together. This repository contains the full stack in one place: the reusable semantic_log_generator package, the backend API, the web UI, the demo simulations, and the documentation.

In practice, a robot or simulator builds semantic logs, the backend receives them and manages the graph behind the scenes, and the UI turns that data into reports, graph views, queries, and audit workflows.

Demo video

Quickstart

If you want the shortest meaningful run, this is the right path. It starts the centralized stack, loads the UC-02 demo dataset, and opens the UI with real interaction data already prepared for reports and graph exploration.

1. Clone the repository and enter it

git clone https://github.com/gsi-upm/semantic_ethical_glass_box.git
cd semantic_ethical_glass_box

2. Create the local environment file

cp .env.example .env

For a first run, set only:

VIRTUOSO_PASSWORD=change-this-password

Leave SECRET_KEY empty so authentication stays disabled during the demo.

3. Start the stack

docker compose -f docker-compose.yaml pull
docker compose -f docker-compose.yaml up -d

4. Create a small Python environment for the demo loader

python3 -m venv .segb_env
./.segb_env/bin/python -m pip install -U pip
./.segb_env/bin/python -m pip install -e packages/semantic_log_generator
./.segb_env/bin/python -m pip install pydantic

5. Load the UC-02 report-ready dataset

./.segb_env/bin/python -m examples.simulations.run_use_case_02_report_ready_dataset \
  --publish-url http://localhost:5000 \
  --no-print-ttl

This loader clears the configured graph before inserting the demo dataset.

6. Open the main entry points

• Reports: http://localhost:8080/reports
• Graph view: http://localhost:8080/kg-graph
• Backend API docs: http://localhost:5000/docs

If /reports shows populated cards and /kg-graph shows connected nodes, you have completed the full SEGB loop.

Documentation

The full documentation is available on Read the Docs: semantic-ethical-black-box-segb.readthedocs.io/en/latest

Use these pages as the main reading path:

• First overview: Home
• Package-first onboarding: Package Overview, Install semantic_log_generator, API Reference, Use semantic_log_generator
• First full run: Quickstart
• Conceptual model: Core Concepts and Roles
• First integration: Publish Your First Log
• UI walkthrough: Explore the Web UI
• Shared context flow: Shared Context Workflow
• ROS integration: ROS4HRI Integration
• Deployment and operation: Centralized Deployment, Authentication and JWT
• Protocol and data reference: API and Roles, Ontology

If you prefer to browse the docs from the repository, start at docs/index.md.
