LLM4AD_Next

LLM for Algorithm Design
Automated Algorithm Design powered by Large Language Models and Evolutionary Computation

Overview

LLM4AD is a modular platform that combines Large Language Models (LLMs) with evolutionary computation to automatically design and optimize algorithms. It provides a flexible framework for leveraging AI to explore, generate, and evolve algorithm implementations.

Quick Start

Try Online	Watch Instruction	Read Docs
Run LLM4AD_Next in your browser. No installation or API key required.	Watch the introduction before installing or configuring a local environment.	Use the documentation path map for setup, configuration, examples, and Web UI deployment.

Instruction Video

Features

• 🧠 LLM-Powered Design - Leverage state-of-the-art language models for algorithm ideation and generation
• 🧬 Evolutionary Optimization - Apply genetic algorithms to improve algorithm performance over generations
• 💬 Interactive Configuration - AI-powered consultant guides you through pipeline setup via conversation, generating a complete runnable application (evaluator, algorithm, config, debug runner)
• 🔍 Evolve-Block Advisor - On-demand feasibility/significance/concerns/suggestions for a user-selected code block versus a stated evolution goal
• 🎯 Evolve-Block Recommender - Point the platform at a repo + a goal and get ranked candidate blocks to evolve, each pre-scored by the advisor
• 📊 Flexible Evaluation - Define custom evaluation metrics and benchmarks with the registry-based evaluator system
• 🔌 Multi-Provider Support - Use OpenAI, Anthropic, or any OpenAI-compatible LLM providers
• 🚀 Distributed Computing - Scale experiments using Ray infrastructure
• 📝 YAML Configuration - Declarative configuration with global settings and environment variable support
• 💾 Checkpoint & Resume - Automatic checkpointing to resume interrupted experiments

Run LLM4AD

Option A: Online Demo (No Installation Required)

Use the online demo from Quick Start, or open it directly: Launch Online Demo.

No setup, no API key needed — just open the link and start designing algorithms.

Option B: Local Installation

# Clone the repository
git clone https://github.com/Optima-CityU/LLM4AD_Next.git
cd LLM4AD_Next

# Install dependencies
uv sync

# Configure your LLM provider (see Global Settings section below)
# Or set environment variables directly:
export LLM_BASE_URL="https://api.openai.com/v1"
export LLM_API_KEY="your-api-key"
export LLM_MODEL="gpt-4o"

# Option 1: Interactive configuration (recommended for new users)
llm4ad chat

# Option 2: Run with an existing config file
llm4ad run examples/applications/tsp_benchmark_python/config.yaml

Installation

Requirements

• Python 3.10, 3.11, or 3.12
• uv (recommended) or pip

Install uv (optional)

# macOS / Linux
curl -LsSf https://astral.sh/uv/install.sh | sh

# Windows (PowerShell)
powershell -c "irm https://astral.sh/uv/install.ps1 | iex"

Install LLM4AD

# Clone and install in development mode
git clone https://github.com/Optima-CityU/LLM4AD_Next.git
cd LLM4AD_Next
uv sync

Optional Dependencies

Install specific groups based on your needs:

Group	Description
infra	Distributed computing (Ray, Prometheus)
providers	LLM provider integrations
eval	Evaluation and benchmarking tools
dev	Development tools (testing, linting)
docs	Documentation tools
all	All optional dependencies

# Install with specific extras
uv sync --extra providers --extra infra

Usage

Command Line Interface

# Show help
llm4ad --help

# List registered components
llm4ad list

# Interactive configuration consultant (builds a full application)
llm4ad chat

# Use a specific provider from global settings
llm4ad chat --provider my_provider

# Resume a saved session
llm4ad chat --resume <session_id>

# Run a pipeline
llm4ad run config.yaml

# Evolve-Block Advisor: analyze a selected block against an evolution goal
llm4ad advise -g "minimize comparisons" -r ./solver --file algo.py --range 42:87
llm4ad advise --config advise_config.yaml

# Generate an advisor config template
llm4ad advise-init -o advise_config.yaml

# Evolve-Block Recommender: propose which block to evolve given a repo + goal
llm4ad recommend -g "reduce TSP tour length" -r ./solver

Global Settings

Create ~/.llm4ad/settings.yaml to configure shared providers across all projects:

providers:
  - name: default
    type: openai
    api_key: ${OPENAI_API_KEY}
    model: gpt-4o
  - name: anthropic
    type: anthropic
    api_key: ${ANTHROPIC_API_KEY}
    model: claude-sonnet-4-20250514

Task configs then only need the provider name — credentials and model are resolved from global settings automatically.

Interactive Chat (Task Builder)

llm4ad chat is an interactive assistant that guides you through building a complete LLM4AD application. It runs a three-phase pipeline:

1. Needs Gathering - Conversational interview to understand your problem
2. Building - Generates evaluator, algorithm skeleton with EVOLVE markers, YAML config, and debug runner
3. Review - Presents the generated code for confirmation or modification

For existing projects, the chat can detect and reuse your evaluator, algorithm, config, and dataset — only generating what's missing.

Evolve-Block Advisor

The advisor answers: "Is THIS block worth evolving for THIS goal?" It runs a single LLM call on a user-selected block and returns structured advice — feasibility, significance, concerns, suggestions, rationale.

# Analyze a specific block by file + line range
llm4ad advise -g "minimize comparisons" -r ./solver --file algo.py --range 42:87

# Repo with exactly one EVOLVE-marked block
llm4ad advise -g "reduce tour length" -r ./solver

# Raw snippet (no repo)
llm4ad advise -g "..." --code "$(cat patch.py)"

Python API:

from llm4ad.advisor import advise_block_sync

advice = advise_block_sync(
    goal="minimize comparisons on random inputs",
    repo_path="./solver",
    file_path="algo.py",
    line_range=(42, 87),
    api_key="sk-...",
    model="gpt-4o",
)
print(advice.feasibility, advice.significance)

Evolve-Block Recommender

When a user arrives with only a repo and a goal — no specific selection yet — the recommender proposes which block( s) to evolve. It returns three tiers:

• core: the single most promising minimal block
• expanded: 0-3 widenings of core (same file, include helpers)
• alternatives: 0-3 independent blocks elsewhere worth evolving

# Scan a repo, print JSON to stdout
llm4ad recommend -g "reduce TSP tour length" -r ./solver

# Human-readable panels
llm4ad recommend -g "improve policy reward" -r ./lander --pretty

Python API:

from llm4ad.advisor import recommend_blocks_sync

result = recommend_blocks_sync(
    goal="reduce TSP tour length",
    repo_path="./solver",
    api_key="sk-...",
    model="gpt-4o",
)
print(result.core.file_path, result.core.line_start, result.core.line_end)

Python API

import asyncio
from llm4ad import LLM4AD


async def main():
    llm4ad = LLM4AD("config.yaml")
    result = await llm4ad.run()
    if result.best_individual:
        print(f"Best score: {result.best_individual.score:.4f}")


asyncio.run(main())

Documentation

• Documentation Home
• Quick Start Guide
• Configuration Guide
• Writing Evaluators

Local Development

# Serve documentation with live reload
mkdocs serve

# Build static documentation
mkdocs build

Project Structure

LLM4AD/
├── src/llm4ad/          # Main source code
│   ├── config/           # Configuration schemas and global settings
│   ├── consultant/       # Interactive configuration wizard
│   ├── builder/          # Task builder (analyzer, creator, validator, writer)
│   ├── advisor/          # Evolve-block advisor and recommender
│   ├── provider/         # LLM provider implementations
│   ├── planner/          # Algorithm planning layer
│   ├── coder/            # Code generation layer
│   ├── evaluator/        # Evaluation layer
│   ├── orchestrator/     # Workflow orchestration
│   ├── infra/            # Infrastructure (Ray, monitoring)
│   └── utils/            # Utilities
├── examples/             # Example configurations and applications
├── tests/                # Test suite
└── docs/                 # Documentation

Contributing

Contributions are welcome! Please read our Contributing Guide for details.

# Set up development environment
uv sync --extra all

# Run tests
pytest

# Format code
black src/ tests/
ruff check src/ tests/ --fix

License

This project is licensed under the BSD 3-Clause License - see the LICENSE file for details.

Support

• Documentation
• Discussions
• Issue Tracker
