IoT Group project as part of Year 3 module, IOTS ET0731, in Singapore Poly.
Conceptually, this is a PickLocker service, made in August 2020, before PickNetwork was officially launched in Singapore (to the best of my knowledge was released in 2021).
Implemented using a front-facing Telegram Bot, using AWS lambda functions as a serverless implementation of a control server.
Commands sent to physical ESP32 box/vault thru MQTT Topic.
During this special period of time, most of us will be in favour of not having close contact with strangers. For students and working adults, we sometimes will encounter times when the parcel arrives and we are unable to present at the point of time.This has caused our parcels to be left at the doorstep or kept in the riser, leaving them at risk of being stolen.
It also leads to a waste of resources and time as the delivery man has to come again another day.How can we allow the delivery man to deliver the parcel to the user safely and easily without it costing too much and downloading an additional app.
IOTS repo for telegram bot hosted on aws lambda controlling a vault locking system
- Bryan Wong
- Lim Cheng Ee
- Chen XinHu
- Jia Nan
The Whole flow of Safe Vault Process:
- The vault comes with a owner ID and a default Password -> the user/subscriber of service would need to change to the default password for stronger user authentication.
- At each delivery, out collaboration company will update the database with respective delivery ID and Parcel No. to the matching Box ID
- When the courier reaches the door step, He then will need to key in the Box ID, Parcerl No. along with his staff ID in order to verify himself.
/Register
- Register owner to box by using default password
- Default password given after owner has paid for the box
- Owner generates a new password
- Password is hashed and salted before saved in database
/Unlock
- Unlocks specifc box using password
- password is verified with hashed password in database
/OTP
- Verifies Owner by verifying password and box_id
- Generates OTP and saves to database
- Tracks creation time and save to database
/UnlockOTP
- Checks OTP of specifc box_id
- If OTP is valid and time elapse since creation not longer than 30 minutes
- Sends MQTTS command to unlock box
/delivery
- Verifies delivery_id, box_id, staff_id of delivery man with Company current deliveries database
- delivery_id is unique to each parcel delivery
- staff_id is secret and specifc to specifc delivery staff
- box_id identifies the box
- If credentials valid, sends MQTTS command to unlock Box
/check
- Publishes MQTTS command to specifc box to determine if box has parcels
- ESP32 publishes reply, saved by lambda to database
- Telegram queries database to determine if box has parcels
Cloudwatch Alarms created to send notification on high number of login failures to database (in the event database endpoint exposed)
Creation:
Alarm:
Database backups for the last 7 days in case of database failure
All input like MQTT are logged , when there is error the admin can use cloudwatch
- Each device has its own publish or subscirbe topic
- Uses MQTT protocol
- Permission for lambda to use iot core
.png)
- Rules to trigger lambda using lambda
| DREAD RISK | ||||||
|---|---|---|---|---|---|---|
| Attack | Damage Potential | Reproducibility | Exploitability | Affected Users | Discoverablity | Risk (MAX=5) |
| Spoofing | ||||||
| WiFi access | 3 | 5 | 4 | 2 | 2 | 3.2 |
| Unauth connection (stolen) | 4 | 4 | 1 | 3 | 1 | 2.6 |
| Cloning of hardware | 2 | 4 | 4 | 2 | 4 | 3.2 |
| Session hijack | 4 | 1 | 3 | 1 | 3 | 2.4 |
| Physical | 2 | 1 | 3 | 1 | 1 | 1.6 |
| RF jamming | 4 | 4 | 4 | 2 | 1 | 3 |
| Hardware Error | 3 | 1 | 1 | 1 | 1 | 1.4 |
| Man in the middle | 5 | 2 | 4 | 1 | 5 | 3.4 |
| Modified data | 5 | 2 | 5 | 1 | 4 | 3.4 |
| Door data leak | 4 | 3 | 4 | 2 | 5 | 3.6 |
| UUID Leak | 5 | 1 | 4 | 2 | 5 | 3.4 |
| User ID Leak | 4 | 1 | 4 | 4 | 3 | 3.2 |
| Flooding | 5 | 5 | 4 | 4 | 1 | 3.8 |
| Redirect notification | 4 | 1 | 3 | 1 | 1 | 2 |
| Botnet inclusion | 3 | 1 | 2 | 1 | 5 | 2.4 |
| Cryptojacking | x | x | x | x | x | x |
| Attack | Checklist | TR64 Code | Description |
|---|---|---|---|
| ESP32 | Sturdy and secure Box, ESP32 Certificates for communcations, Lambda/Iot Devices uses unique endpoint and passwords | AP-03 AP-04 DP-02 IA-02 | Enclosure is not easily tampered with. ESP32 uses MQTTS, uses certificates |
| Telegram API | OTP generated for MFA, Clients have unique IDs | IA-02 AP-02 | OTP generated by bot, clients are uniquely identified, Secure Communications |
| AWS system | Passwords are hashed + salted with verified library. Code prevent SQL injection. AWS RDS database, Secure Communications in Virtual Cloud, database backups and Alarms | IA-01 CS-02 DP-03 NP-01 AU-01 | Verified library bcrypt used for hashing and salting. Usage of mysql library prevents SQL injection, services are isolated virtual cloud. Alarm on many unsuccessful login attempts to databse |
Things to prepare:
- The telegram CLi
- Telegram API
- Ubuntu subsystem (for Windows system) Create a telegram bot for under the account used, Download & Configure Telegram Cli using Ubuntu subsystem. Link Telegram account with the Telegram Cli, Loop the text ("commands") within a loop.
| Possible Improvements | Description/Resoning |
|---|---|
| Use trusted library to generate OTP | standard open source library is more secure and has been cross examined by professionals. |
| Password policy | users needs a policy to generate passwords of sufficient strength and mitigate brute-force attacks |
| DDOS protection/Rate limiting | There is no rate limiting for telegram bot on lambda, DDOS attacks can bring down the usability of Safe Vault |
| Hashing OTP | Prevent OTP from being used if database leaked |
| Input validation for telegrambot | Inputs can be checked to ensure utf-8 |
| More secure randomiser | Math.Random() is not cryptographically secure, a more secure library should be used |
| Non-repuditation | Safe Vault potentially vulnearble to replay attacks |
| 3D printer casing | Prevent Physical tampering |
- Servo motor
- Stripboard
- female pin
- LDR
- Ultrasonic sensor
- Box
Inside Circuitry of box
Outside Appearance of box
.png){kind=link}
bcrypt https://www.npmjs.com/package/bcryptjs
sync-mysql https://www.npmjs.com/package/sync-mysql
telegram-cli
https://iamondemand.com/blog/building-your-first-serverless-telegram-bot/ https://docs.aws.amazon.com/iot/latest/developerguide/iot-lambda-rule.html
http://amicus.com.sg/index.php?route=product/product&product_id=3889 https://create.arduino.cc/projecthub/csw1/ultrasonic-sensor-with-arduino-uno-f33ca1 https://sea.banggood.com/10pcs-8P-2_54MM-Stackable-Long-Connector-Female-Pin-Header-p-1205369.html?cur_warehouse=CN https://www.rapidonline.com/feetech-fs90r-360-continuous-rotation-micro-servo-37-1335 https://en.wikipedia.org/wiki/Stripboard
